برد توسعه NodeMcu دارای هسته ESP8266 و مبدل CH340G

برد توسعه NodeMcu دارای هسته ESP8266 و مبدل CH340G راه بسیار خوبی برای توسعه ی ESP8266 است. NodeMCU بر پایه ی ESP-12 برای تامین GPIO ، PWM ، ADC, I2C و ارتباط تک سیمه است.

ویژگی های برد کنترلی NODEMCU به همراه ماژول WIFI با مبدل CH340G :

• درایور USB : تراشه CH340
• ولتاژ ورودی : حداکثر 5 ولت
• فرکانس : 2.4ghz
• 802.11 b/g/n
• بهبود مدار مدار محیطی، تطبیق امپدانس افزایش یافته، خروجی سیگنال بهتر.
• دارای پایداری بالا
• دارای رگولاتور LM1117 با خروجی 3.3V 500mA
• دارای آداپتور داخلی USB به TTL

مشخصات برد NodeMcu دارای هسته ESP8266 :

the following are the benefits for 2.4G wifi Development Board which is based on ESP12E and CH340G:
modern highlevel mature LUA on technology. it is an integrated unit with all the resources available on board. it is super simple to supplement your existing Ar duino projects or any development board that has I / O pins available.
modern Internet development tools such as Node. js can enjoy the NodeMCU with the builtin API to put your idea on the fast track immediately.
it is built on the maturity ESP8266 technologies to leverage the abundant resources available on the web.
it has ESP12E based on WiFi integrated edge series to provide a GPIO, PWM, ADC, I2C and 1WIRE resources at your fingertips. please refer to the details list for ESP12E.
It has builtin USBTTL series with super reliable industrial strength CH340G for better stability on all supported platforms.
